ULPA Clean rooms & Laboratories PRODUCT C A T A L O G 2025 CRUMA | Laboratory equipment made in Barcelona
אודות החברה בע"מ משווקת ULPA Clean Rooms & Laboratories חברת בישראל מנדפים כימיים בסינון פחם פעיל ומנדפים למינריים , חברה ספרדית מובילה בתחום. Cruma מתוצרת המנדפים הכימיים בסינון פחם פעיל מיועדים לטיפול בחומרים כימיים רעילים, ומספקים הגנה על הסביבה והמפעיל במעבדה .NFX 15211 במהלך יישומים כימיים בהתאם לתקן המנדפים הלמינריים מספקים סביבת עבודה נקייה .ISO 14644 בהתאם לתקן ISO 5 ברמת ניקיון מאפשר ללקוחות בישראל Cruma- ל ULPA שיתוף הפעולה בין ליהנות ממוצרים איכותיים ומתקדמים, המותאמים לצרכי המעבדות השונות.
USES √ Laboratory food industries in general √ Transfer of drugs in the pharmacy department √ Hematology and clinical analysis √ Filled with antibiotics and injectable drugs (except cytostatic) microscopic analysis √ Tissue culture bags reconstitution of parenteral methods of assisted fertilization techniques √ Micropropagation, Plant cell cultures, Water quality control, manufacturing of electronic devices... NEW FEATURES CRUMA vertical laminar flow hood with ISO Class 5 air purity creates a sterile environment free of particles and/or microorganisms that ensures the reliability of any test inside the hood. It incorporates a HEPA H-14 absolute filter whose minimum efficiency is of 99.995% for particles of 0.3 µm, and a 15W UV germicide lamp designed to decontaminate the hood before and after each use. Cruma has updated the cabinet with the latest techniques for a better protection of the samples. In compliance with the EN-1822, DIN-24184, US St-209, ISO-14644, EN-ISO 90001:2000. It includes new important technical features in order to satisfy the operator in his everyday task and his protection at work, taking care of the environment as well. All this with the same quality as always and up to 7 year guarantee. VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION MAIN FEATURES √ Manufacture: outer surfaces made of cold rolled steel gray / ocher coating, stoveenamelled, resistant to the chemical compounds used for sterilization √ Worktop: the surface of the working chamber is in secured safety glass √ Absolute HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. Filter is in accordance with EN-779:1996 and EN-1822:1998 √ Fan: centrifugal double suction, suitable to provide laminar flow in the workspace √ Control panel with soft-touch keyboard and switch for LED and optional UV lamps; the air speed is kept at a constant rate thanks to the HEPA filter which is electronically self- regulated, electronic control air speed and control key to slow it down √ Lighting: LED lamp placed in the central part of the cabinet, for a better light distribution over the working surface Number of filters Number of IP44 fans Average face velocity Total electrical power consumption Voltage-Frequency LED light intensity UV germicidal lamp Noise level Packaging: 100% recycled wooden box with international phytosanitary certificate 1 1 0,40 m/s 102 W 110-220 V / 50-60 Hz 900 Lux 15W 48 dB 0,28 m3 65 Kg Volume Weight TECHNICAL FEATURES www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 More information on the new LCD display √ New size 127x34mm display √ Type of filter installed, working hours, expiration date and next revision date √ Countdown timer, clock and calendar New features and components √ Initial cycle flow adequacy and final purge cycle √ Fault LED √ Control of air flow through Microprocessor √ HEPA filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Next validation warning √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm by hours & by date √ Equipment without filter alarm
SIZES (mm) 600 550 600 576 276 600 587 600 556 620 937 75 390 135 600 Vitrina 600 550 600 576 276 600 587 600 556 620 937 75 390 135 600 Vitrina CRUMA 67 E VISTAS 670 FLVERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION SIZES (MM) External Internal Width 600 575 600 560 930 630 Depth Height Width Depth Height MAIN STRUCTURE Metallic parts 1.2 mm galvanized steel, coated with antiacid polymer powder resin thermo-hardened at 200 ° C Transparent polymethylmethacrylate 8 mm thick (light transmission of 93%) Side Panels
VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION OPTIONAL EQUIPMENT Tubular stand for 670 Stand with wheels Movilair for 670 Gas tap Double gas tap Vacuum tap Double vacuum tap Electric socket Double electric socket SERIAL EQUIPMENT Electronic circuit with large format LCD display Filters controlled by microprocessor Illumination Digital timer with audible warning Clock and Calendar Work surface G4 prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters are provided with a microchip with mini USB connection identifying the type of filter installed, the expiry date and the serial number 96 LED high light intensity and low consumption 16 Watts / 900 Lux Hourmeter for the control and warning of the work in the cabinet Display of date and time Liquid retention tray (2-10 liters) with working surface in white tempered glass Pre-filtering class G4 biofibre synthetic blanket 7 years ACCORDING TO STANDARDS Filters Quality CSA Z 316.5-94 (Canada) EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) EN-141:2001 (Gas Filters) UNE EN ISO 9001:2015 www.cruma.es export@cruma.es We recognise our responsability and dependence towards a healthy environment and, therefore, we destinate more than 7% of our annual budget in innovating and developing new products for the lab operator
DISTRIBUTED BY: & Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es
USES √ Laboratory food industries in general √ Transfer of drugs in the pharmacy department √ Hematology and clinical analysis √ Filled with antibiotics and injectable drugs (except cytostatic) microscopic analysis √ Tissue culture bags reconstitution of parenteral methods of assisted fertilization techniques √ Micropropagation, Plant cell cultures, Water quality control, manufacturing of electronic devices... CRUMA vertical laminar flow hood with ISO Class 5 air purity creates a sterile environment free of particles and/or microorganisms that ensures the reliability of any test inside the hood. It incorporates a HEPA H-14 absolute filter whose minimum efficiency is of 99.995% for particles of 0.3 µm, and a 15W UV germicide lamp designed to decontaminate the hood before and after each use. Cruma has updated the cabinet with the latest techniques for a better protection of the samples. In compliance with the EN-1822, DIN-24184, US St-209, ISO-14644, EN-ISO 90001:2000. It includes new important technical features in order to satisfy the operator in his everyday task and his protection at work, taking care of the environment as well. All this with the same quality as always and up to 7 year guarantee. VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION MAIN FEATURES √ Manufacture: outer surfaces made of cold rolled steel gray / ocher coating, stoveenamelled, resistant to the chemical compounds used for sterilization √ Worktop: the surface of the working chamber is in secured safety glass √ Absolute HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. Filter is in accordance with EN-779:1996 and EN-1822:1998 √ Fan: centrifugal double suction, suitable to provide laminar flow in the workspace √ Control panel with soft-touch keyboard and switch for LED and optional UV lamps; the air speed is kept at a constant rate thanks to the HEPA filter which is electronically self- regulated, electronic control air speed and control key to slow it down √ Lighting: LED lamp placed in the central part of the cabinet, for a better light distribution over the working surface www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 NEW FEATURES 1 1 0,40 m/s 226 W 110-220 V / 50-60 Hz 900 Lux 15W 50 dB 0,42 m3 92 Kg TECHNICAL FEATURES Number of filters Number of IP44 fans Average face velocity Total electrical power consumption Voltage-Frequency LED light intensity UV germicidal lamp Noise level Packaging: 100% recycled wooden box with international phytosanitary certificate Volume Weight More information on the new LCD display √ New size 127x34mm display √ Type of filter installed, working hours, expiration date and next revision date √ Countdown timer, clock and calendar New features and components √ Initial cycle flow adequacy and final purge cycle √ Fault LED √ Control of air flow through Microprocessor √ HEPA filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Next validation warning √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm by hours & by date √ Equipment without filter alarm
SIZES (mm) 800 750 329 800 776 800 597 610 1122 720 390 135 75 600 566 Vitrina C VIS 800 750 329 800 776 800 597 610 1122 720 390 135 75 600 566 Vitrina CRUMA 870 Escala: VISTAS 870 FL- rev VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION MAIN STRUCTURE Metallic parts 1.2 mm galvanized steel, coated with antiacid polymer powder resin thermo-hardened at 200 ° C Transparent polymethylmethacrylate 8 mm thick (light transmission of 93%) Side Panels SIZES (MM) External Internal Width 800 775 600 560 1125 740 Depth Height Width Depth Height
VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION OPTIONAL EQUIPMENT Tubular stand Stand with wheels Movilair Gas tap Double gas tap Vacuum tap Double vacuum tap Electric socket Double electric socket SERIAL EQUIPMENT Electronic circuit with large format LCD display Filters controlled by microprocessor Illumination Digital timer with audible warning Clock and Calendar Work surface G4 prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters are provided with a microchip with mini USB connection identifying the type of filter installed, the expiry date and the serial number 96 LED high light intensity and low consumption 16 Watts / 900 Lux Hourmeter for the control and warning of the work in the cabinet Display of date and time Liquid retention tray (2-10 liters) with working surface in white tempered glass Pre-filtering class G4 biofibre synthetic blanket 7 years ACCORDING TO STANDARDS Filters Quality CSA Z 316.5-94 (Canada) EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) EN-141:2001 (Gas Filters) UNE EN ISO 9001:2015 www.cruma.es export@cruma.es We recognise our responsability and dependence towards a healthy environment and, therefore, we destinate more than 7% of our annual budget in innovating and developing new products for the lab operator
DISTRIBUTED BY: & Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es
Number of filtering columns Number of IP44 fans Average face velocity Total electrical power consumption Voltage/Frequency Illumination level LED UV germicidal lamp Noise level Packaging: 100% recyclable Wood box with international phytosanitary certificate 1 1 0,40 m/s 226 W 110-220 V / 50-60 Hz 900 Lux 15W 50 dB 0,74 m3 112 Kg Volume Weight TECHNICAL INFORMATION USES Cruma breaks with the tradition of removable laminar flow cabinets offering the new Cruma FL-1, an innovative cabinet whole body. Furthermore, the new cabinet Cruma FL-1 combines a striking and unique exterior design with the best technology and internal development. However, to meet the operator in his everyday work and protect it in their work caring for the environment. VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 NEW FEATURES √ Laboratory food industries in general √ Transfer of drugs in the pharmacy department √ Hematology and clinical analysis √ Filled with antibiotics and injectable drugs (except cytostatic) microscopic analysis √ Tissue culture bags reconstitution of parenteral methods of assisted fertilization techniques √ Micropropagation techniques. Plant cell cultures. √ Water quality control √ Manufacturing of electronic devices... MAIN FEATURES √ Manufacture: outer surfaces made of cold rolled steel gray / ocher coating, stoveenamelled, resistant to the chemical compounds used for sterilization √ Worktop: the surface of the working chamber is in secured safety glass √ Absolute HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. Filter is in accordance with EN-779:1996 and EN-1822:1998 √ Fan: centrifugal double suction, suitable to provide laminar flow in the workspace √ Control panel with soft-touch keyboard and switch for LED and optional UV lamps; the air speed is kept at a constant rate thanks to the HEPA filter which is electronically self- regulated, electronic control air speed and control key to slow it down √ Lighting: LED lamp placed in the central part of the cabinet, for a better light distribution over the working surface More information on the new LCD display √ New size 127x34mm display √ Type of filter installed, working hours, expiration date and next revision date √ Countdown timer √ Clock and calendar New features and components √ Initial cycle flow adequacy and final purge cycle √ Fault LED √ Control of air flow through Microprocessor √ HEPA filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Next validation warning √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm by hours √ Expired filter alarm by date √ Equipment without filter alarm
SIZES (mm) 463 710 750 800 601 800 390 75 600 560 610 1137 1314 V VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION STRUCTURE Metallic parts 1.2 mm galvanized steel, coated with antiacid polymer powder resin thermo-hardened at 200 ° C Transparent polymethylmethacrylate 6 mm thick (light transmission of 93%) Front Panel SIZES (mm) Exterior Interior Width 800 710 600 556 1137 610 Depth Height Width Depth Height
VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION ACCORDING TO STANDARDS Filters Quality EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) UNE EN ISO 9001:2015 www.cruma.es export@cruma.es OPTIONAL EQUIPMENT Tubular stand Stand with wheels Movilair Double gas tap Vacuum tap Double vacuum tap Double electric socket We recognise our responsability and dependence towards a healthy environment and, therefore, we destinate more than 7% of our annual budget in innovating and developing new products for the lab operator STANDARD EQUIPMENT Electronic circuit with large format LCD display Filters controlled by microprocessor Illumination Digital timer with audible warning Electrical plug Clock and Calendar Gas tap Work surface G4 prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters are provided with a microchip with mini USB connection identifying the type of filter installed, the expiry date and the serial number 96 LED high light intensity and low consumption 16 Watts / 900 Lux Hourmeter for the control and warning of the work in the cabinet Placed in the internal roof of the cabinet and conmuted with the electronic circuit Display of date and time Placed in the internal of the cabinet Liquid retention tray (2-10 liters) with working surface in white tempered glass Pre-filtering class G4 biofibre synthetic blanket 7 years
DISTRIBUTED BY: & Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es
Number of filtering columns Number of IP44 fans Average face velocity Total electrical power consumption Voltage/Frequency Illumination level LED UV germicidal lamp Noise level Packaging: 100% recyclable Wood box with international phytosanitary certificate 1 1 0,40 m/s 226 W 110-220 V / 50-60 Hz 900 Lux 15W 50 dB 0,95 m3 142 Kg Volume Weight TECHNICAL INFORMATION USES Cruma breaks with the tradition of removable laminar flow cabinets offering the new Cruma FL-2, an innovative cabin whole body. Furthermore, the new cabin Cruma FL-2 combines a striking and unique exterior design with the best technology and internal development. However, to meet the operator in his everyday work and protect it in their work caring for the environment. VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 √ Laboratory food industries in general √ Transfer of drugs in the pharmacy department √ Hematology and clinical analysis √ Filled with antibiotics and injectable drugs (except cytostatic) microscopic analysis √ Tissue culture bags reconstitution of parenteral methods of assisted fertilization techniques √ Micropropagation techniques. Plant cell cultures. √ Water quality control √ Manufacturing of electronic devices... MAIN FEATURES √ Manufacture: outer surfaces made of cold rolled steel gray / ocher coating, stoveenamelled, resistant to the chemical compounds used for sterilization √ Worktop: the surface of the working chamber is in secured safety glass √ Absolute HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. Filter is in accordance with EN-779:1996 and EN-1822:1998 √ Fan: centrifugal double suction, suitable to provide laminar flow in the workspace √ Control panel with soft-touch keyboard and switch for LED and optional UV lamps; the air speed is kept at a constant rate thanks to the HEPA filter which is electronically self- regulated, electronic control air speed and control key to slow it down √ Lighting: LED lamp placed in the central part of the cabinet, for a better light distribution over the working surface MAIN FEATURES NEW FEATURES More information on the new LCD display √ New size 127x34mm display √ Type of filter installed, working hours, expiration date and next revision date √ Countdown timer √ Clock and calendar New features and components √ Initial cycle flow adequacy and final purge cycle √ Fault LED √ Control of air flow through Microprocessor √ HEPA filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Next validation warning √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm by hours √ Expired filter alarm by date √ Equipment without filter alarm
SIZES (mm) VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION SIZES (mm) Exterior Interior Width 1200 1110 600 556 1137 610 Depth Height Width Depth Height 463 1110 1150 1200 601 1200 390 75 600 560 610 1137 1314 Vitrina CRUMA FL Escala VISTAS FL-2- re 1110 1150 1200 1200 390 75 600 560 610 1137 135 1314 Vitrina CRUMA FL-2 Escala: 1:10 VISTAS FL-2- rev.: 04 STRUCTURE Metallic parts 1.2 mm galvanized steel, coated with antiacid polymer powder resin thermo-hardened at 200 ° C Transparent polymethylmethacrylate 6 mm thick (light transmission of 93%) Front Panel
VERTICAL LAMINAR FLOW FOR SAMPLE PROTECTION www.cruma.es export@cruma.es We recognise our responsability and dependence towards a healthy environment and, therefore, we destinate more than 7% of our annual budget in innovating and developing new products for the lab operator STANDARD EQUIPMENT Electronic circuit with large format LCD display Filters controlled by microprocessor Illumination Digital timer with audible warning Electrical plug Clock and Calendar Gas tap Work surface G4 prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters are provided with a microchip with mini USB connection identifying the type of filter installed, the expiry date and the serial number 96 LED high light intensity and low consumption 16 Watts / 900 Lux Hourmeter for the control and warning of the work in the cabinet Placed in the internal roof of the cabinet and conmuted with the electronic circuit Display of date and time Placed in the internal of the cabinet Liquid retention tray (2-10 liters) with working surface in white tempered glass Pre-filtering class G4 biofibre synthetic blanket 7 years ACCORDING TO STANDARDS Filters Quality EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) UNE EN ISO 9001:2015 OPTIONAL EQUIPMENT Tubular stand Stand with wheels Movilair Double gas tap Vacuum tap Double vacuum tap Double electric socket
DISTRIBUTED BY: & Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es
Number of filtering columns Number of IP44 fans Average face velocity Total electrical power consumption Voltage/Frequency Illumination level LED Noise Level Packaging: 100% recyclable Wood box with international phytosanitary certificate 1 2 0,50 m/s 406 W 110-220 V / 50-60 Hz 18 W / 900 Lux 45 dB 0,65 m3 120 Kg Volume Weight TECHNICAL INFORMATION USES √ Parenteral bags reconstruction √ Assisted reproductive technologies √ Micropropagation √ Plant Cell Cultures √ Food and water quality control √ Dust Protection in optics and electronics industry NEW TECHNICAL FEATURES The new Cruma HZ-2 is our large horizontal laminar flow cabinet Class ISO 5 (former class 100) ideal for works that should ensure the protection of the products against external and crosscontamination. The unique mounting system of the sidewalls, positioned inside the perimeter of the filter, prevents contaminants from entering into the work area through the same filter frame thanks to the Venturi-effect. The air passes through a polyurethane fiber G-4 prefilter and it is pushed by the fan to the retention plenum, then goes through the absolute H-14 HEPA filter and reaches the working chamber. The airflow leaving the H-14 filter placed in front of the operator, at a constant speed, creates an ISO 5 sterile area removing any possible contaminants from the product you are working with. HORIZONTAL LAMINAR FLOW CABINET TO PROTECT THE SAMPLE MAIN FEATURES √ Manufacture: outer surfaces made of cold rolled steel gray / ocher coating, stoveenamelled, resistant to the chemical compounds used for sterilization √ Worktop: the surface of the working chamber is in stainless steel AISI 304 2B √ Acrylic transparent side walls √ Absolute HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. Filter is in accordance with EN-779:1996 and EN-1822:1998 √ Fan: centrifugal double suction, suitable to provide laminar flow in the workspace √ Control panel with soft-touch keyboard and switch for LED and optional UV lamps; the air speed is kept at a constant rate thanks to the HEPA filter which is electronically self- regulated, electronic control air speed and control key to slow it down √ Filter life timer √ Lighting: LED lamp placed in the central part of the cabinet, for a better light distribution over the working surface www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 More info on the new LCD screen √ Large format 127x34mm √ Type of filter installed, working hours, expiry date and next revision √ Countdown Timer √ Clock and calendar New features and components √ Initial cycle flow adequacy and final cycle purge √ Fault LED indicator √ Air Flow Control by Microprocessor √ HEPA filters with electronic chip √ LED Lighting New alarms and warnings √ Next Validation √ Few hours of filter life √ Countdown timer √ Filter has expired (hours of use) √ Filters has expired (expiry date) √ Cabinet without filter
SIZES (mm) STRUCTURE Metallic parts 1.2 mm galvanized steel, coated with antiacid polymer powder resin thermo-hardened at 200 ° C Transparent polymethylmethacrylate 8 mm thick (light transmission of 93%) Side Panels HORIZONTAL LAMINAR FLOW CABINET TO PROTECT THE SAMPLE SIZES (mm) Exterior Interior Width 1295 1169 770 600 977 633 Depth Height Width Depth Height SIZES(mm) 1295 1169 1290 1295 770 633 170 600 770 977 1295 1169 1290 1295 633 170 600 770 977 VIST
We recognise our responsability and dependence towards a healthy environment and, therefore, we destinate more than 7% of our annual budget in innovating and developing new products for the lab operator HORIZONTAL LAMINAR FLOW CABINET TO PROTECT THE SAMPLE STANDARD EQUIPMENT Electronic circuit with large format LCD display Filters controlled by microprocessor Illumination Digital timer with audible warning Electrical plug Clock and Calendar Steel work surface G4 prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters are provided with a microchip with mini USB connection identifying the type of filter installed, the expiry date and the serial number 96 LED high light intensity and low consumption 18 Watts / 900 Lux Hourmeter for the control and warning of the work in the cabinet Placed in the internal roof of the cabinet and conmuted with the electronic circuit Display of date and time Worktop of stainless steel surface AISI 304 2B Pre-filtering class G4 biofibre synthetic blanket 7 years OPTIONAL EQUIPMENT Tubular stand Portable UV light (2 x 15 Watt UV lamps) COMPLIANCE TO STANDARDS Filters Quality EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) UNE EN ISO 9001:2015 www.cruma.es export@cruma.es
DISTRIBUTED BY: & Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es
Number of filtering columns Number of IP44 fans Average face velocity Total electrical power consumption Voltage/Frequency Illumination level LED Noise Level Packaging: 100% recyclable Wood box with international phytosanitary certificate 1 1 0,50 m/s 244 W 110-220 V / 50-60 Hz 18 W / 900 Lux 45 dB 0,385 m3 80 Kg Volume Weight TECHNICAL INFORMATION USES √ Parenteral bags reconstruction √ Assisted reproductive technologies √ Micropropagation √ Plant Cell Cultures √ Food and water quality control √ Dust Protection in optics and electronics industry NEW TECHNICAL FEATURES The new Cruma HZ-1 is our little horizontal laminar flow cabinet Class ISO 5 (former class 100) ideal for works that should ensure the protection of the products against external and cross-contamination. The unique mounting system of the sidewalls, positioned inside the perimeter of the filter, prevents contaminants from entering into the work area through the same filter frame thanks to the Venturi-effect. The air passes through a polyurethane fiber G-4 prefilter and it is pushed by the fan to the retention plenum, then goes through the absolute H-14 HEPA filter and reaches the working chamber. The airflow leaving the H-14 filter placed in front of the operator, at a constant speed, creates an ISO 5 sterile area removing any possible contaminants from the product you are working with. HORIZONTAL LAMINAR FLOW CABINET TO PROTECT THE SAMPLE MAIN FEATURES √ Manufacture: outer surfaces made of cold rolled steel gray / ocher coating, stoveenamelled, resistant to the chemical compounds used for sterilization √ Worktop: the surface of the working chamber is in stainless steel AISI 304 2B √ Acrylic transparent side walls √ Absolute HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. Filter is in accordance with EN-779:1996 and EN-1822:1998 √ Fan: centrifugal double suction, suitable to provide laminar flow in the workspace √ Control panel with soft-touch keyboard and switch for LED and optional UV lamps; the air speed is kept at a constant rate thanks to the HEPA filter which is electronically self- regulated, electronic control air speed and control key to slow it down √ Filter life timer √ Lighting: LED lamp placed in the central part of the cabinet, for a better light distribution over the working surface www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 More info on the new LCD screen √ Large format 127x34mm √ Type of filter installed, working hours, expiry date and next revision √ Countdown Timer √ Clock and calendar New features and components √ Initial cycle flow adequacy and final cycle purge √ Fault LED indicator √ Air Flow Control by Microprocessor √ HEPA filters with electronic chip √ LED Lighting New alarms and warnings √ Next Validation √ Few hours of filter life √ Countdown timer √ Filter has expired (hours of use) √ Filters has expired (expiry date) √ Cabinet without filter
STRUCTURE Metallic parts 1.2 mm galvanized steel, coated with antiacid polymer powder resin thermo-hardened at 200 ° C Transparent polymethylmethacrylate 8 mm thick (light transmission of 93%) Side Panels HORIZONTAL LAMINAR FLOW CABINET TO PROTECT THE SAMPLE SIZES (mm) Exterior Interior Width 895 700 771 600 971 633 Depth Height Width Depth Height SIZES (mm) SIZES(mm) 895 770 890 895 770 977 633 170 600 770 895 770 890 895 770 977 633 170 600 770
HORIZONTAL LAMINAR FLOW CABINET TO PROTECT THE SAMPLE STANDARD EQUIPMENT Electronic circuit with large format LCD display Filters controlled by microprocessor Illumination Digital timer with audible warning Electrical plug Clock and Calendar Steel work surface G4 prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters are provided with a microchip with mini USB connection identifying the type of filter installed, the expiry date and the serial number 96 LED high light intensity and low consumption 18 Watts / 900 Lux Hourmeter for the control and warning of the work in the cabinet Placed in the internal roof of the cabinet and conmuted with the electronic circuit Display of date and time Worktop of stainless steel surface AISI 304 2B Pre-filtering class G4 biofibre synthetic blanket 7 years OPTIONAL EQUIPMENT Tubular stand Portable UV light (2 x 15 Watt UV lamps) COMPLIANCE TO STANDARDS Filters Quality EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) UNE EN ISO 9001:2015 www.cruma.es export@cruma.es We recognise our responsability and dependence towards a healthy environment and, therefore, we destinate more than 7% of our annual budget in innovating and developing new products for the lab operator
DISTRIBUTED BY: & Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es
The CRUMA 2010FL cupboards have been designed for the sterile storage of clothing for clean room and drying of bacterial agents and cultures non-hazardous for operators. Creating a dust-free and non-bacterial air environment in the working chamber thanks to the HEPA-H14 filtration. The 2010FL cupboards are devices that are used both separately and inside a clean rooms. This cupboard is generally defined as a “Clean Zone” characterized by its own supply of filtered air. In recent years, the use of “Clean Zones” has extended from the field of research and production to other fields such as aerospace, biotechnology, pharmaceuticals and the food industry. There are various applications where they are used, from laboratories to medical research. CERTIFIED –Manufactured in Spain and certified by an external laboratory according to international standards and applying the criteria of ISO 9001. ABSOLUTE HEPA H-14 filter with flow equalizer, efficiency greater than 99.995% on 0.3 micron particles. NEW FEATURES OPERATING PRINCIPLE The contaminated air from the room is drawn into the upper part of the Cruma2010FL cupboard by the motor. This air is driven through an installed HEPA H-14 rated filter (manufactured according to EN1822). This creates a safe particle-free environment, generating a sterile airflow of ISO 5 classification. The air, at a constant speed, flows vertically downwards through the cupboard, generating a clean area and protecting the product from external contamination. Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 More information on the new LCD display √ New size 127x34mm display √ Type of filter installed, working hours, expiration date and next revision date √ Countdown timer √ Clock and calendar New features and components √ Fault LED √ Control of air flow through Microprocessor √ Filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm (by hours) √ Expired filter alarm (by date) √ Equipment without filter alarm SIZES (MM) External Internal Width 800 760 500 468 1845 1295 Depth Height Width Depth Height 1 0,35 m/s 1 80l. max. (20l. per shelf) 0,567 m3 91 W 110-220 V - 50-60 Hz 1200 lm 59 dB 1,1 m3 150 Kg Number of filtration columns Average velocity Number of IP44 fans Storage capacity (litres) Internal volume of the cupboard Total electrical power consumption Voltage-Frequency LED light intensity Noise level Packaging: 100% recycled wooden box with international phytosanitary certificate Volume Weight TECHNICAL FEATURES www.cruma.es export@cruma.es
800 720 760 800 1301 800 548 1388 50 548 420 1765 468 1845 Armario CRUMA 870 Escala: 1:10 VISTAS ARMARIO- rev.: 10 SIZES(mm) OPTIONAL EQUIPMENT Voltage / Frequency Additional shelves 125 V / 50 Hz 2 additional shelves with holes that support up to a weight of 20l / 25kg each MAIN STRUCTURE Metal parts: base frame, rear wall and head 1.2 mm galvanized coated steel with anti acid polymer resin powder heat-hardened at 200 °C Transparent polymethylmethacrylate 6 mm thick (light transmission of 93%) Front and side panels SERIAL EQUIPMENT Electronic circuit with large format LCD screen Electronic control device for filters replacement Illumination Electronic cronometre with audible alarm Clock and calendar Lock Shelves Inert absorbent mat G4 Prefilter Warranty Security levels: level 1 for users and level 2 for maintenance users The filters incorporate a chip with USB connection that identifies the type of filter installed and the expiry date LED Tube high light intensity and low power consumption - 16 Watts / 1500lm To program the work inside the fume hood Display of date and time Key lock 4 shelves with holes that support up to a weight of 20l / 25kg each Absorbent mat for liquid absorption in case of spillage G4 class pre-filtering blanket of synthetic biofibres (according to EN-779) for the retention of atmospheric dust 7 years www.cruma.es export@cruma.es
& DISTRIBUTED BY: Pol. Ind. Fonollar - Andorra, 19A - 08830 Sant Boi de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es PRECISION WEIGHING CABINET
Perfect for small working spaces. This ductless fume hood is recommended to remove from the working area gaseous polluting agents and/or solid particles/aerosols in a simple, efficient and cost effective way, protecting both the user and the environment. CRUMA 670 ductless fume hood uses the Cruma filtration system. Cruma ductless fume hoods designed to handle low toxic products are made of steel plate with antiacid polymerized epoxy coating and methylpropileno of high resistance. PROTECTION OF AND RESPECT FOR THE ENVIRONMENT –The toxic chemical products are not released outside but retained within the filter. COST SAVINGS AND FAST SET UP –No building work is needed to install ducts to channel the gas outside, which means fewer problems for a laboratory working at full capacity. FLEXIBLE –It can be used in areas where it is difficult to remove/extract contaminated air, such as from the lower levels in buildings that have a number of floors. ENERGY SAVINGS –The air that is sucked in is not expelled but recirculated back into the lab after the contaminating substances have been removed. This means that it is not necessary to increase the use of the air-conditioning or heating systems to compensate for the air removed. CERTIFIED –Manufactured in Spain and certified by an external laboratory according to international standards and applying the criteria of ISO 9001. USES General chemistry involving small volumes of reagents or chemical compounds at ambient/moderate temperature in all types of laboratories: √ Research laboratories √ Quality control laboratories √ Clinical and hospital laboratories √ University and school laboratories …In general, in any kind of laboratory. NEW FEATURES TECHNICAL FEATURES Number of filtration columns Number of filters Number of IP44 fans Average volume of treated air Average face velocity Internal volume of the cabinet Renewals inside the cabinet / min Total electrical power consumption Voltage-Frequency LED light intensity Noise level Packaging: 100% recycled wooden box with international phytosanitary certificate Volume Weight 1 1 to 2 1 155 m3/h 0,50 m/s 0,181 m3 14,3 91 W 110-220 V - 50-60 Hz 18 W - 900 Lux 48 dB 0,28 m3 58 Kg SIZES (MM) External Internal Width Depth Height Width Depth Height www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 DUCTLESS FUME HOOD More information on the new LCD display √ New size 127x34mm display √ Air speed continuously monitored √ Type of filter installed, working hours, expiration date and next revision date √ Open door warning through electronic photocell √ Countdown timer √ Clock and calendar New features and components √ Initial air flow cycle adequacy and final purge cycle √ Fault LED √ Control of air flow through Microprocessor √ Activated carbon filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Open door warning √ Open door in off mode warning √ 60h of filter use warning √ Next validation warning √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm (by hours) √ Expired filter alarm (by date) √ Temperature alarm √ Equipment without filter alarm √ Low barrier alarm 600 576 600 556 937 620
SIZES (mm) DUCTLESS FUME HOOD SERIAL EQUIPMENT Electronic circuit with large format LCD screen Electronic anemometer device Photocell sensor device for open door detection Electronic control device for filters replacement Illumination Sampling system to analize the filtered air at the exhaust 60 hours alarm Electronic cronometre with audible alarm Clock and calendar Working surface 1 G4 Prefilter Cable entry holes (2) Chemical Listing Warranty Security levels: level 1 for users and level 2 for maintenance users Electronic sensor monitoring continuously air face velocity Electric device with open door alarm The filters incorporate a microchip with miniUSB connection that identifies the type of filter installed, the expiry date and the serial no. 96 LED Tube high light intensity and low power consumption - 16 Watts / 700 Lux To detect the level of filter saturation Countdown timer according to French NF X 15-211:2009 To program the work inside the fume hood Display of date and time Spill retention tray (2-10 liters) with working surface in white tempered glass G4 class pre-filtering blanket of synthetic biofibres (according to EN-779) for the retention of atmospheric dust Access to the rear wall for cables and / or services entry Guide of retained products by type of filter 7 years OPTIONAL EQUIPMENT Movilair Tubular steel stand Working surface 2 Working surface 3 Transparent rear back pannel Voltage / Frequency Filter test kit Stand with wheels and internal tray in Epoxy coated steel Support stand in Epoxy coated steel Spill retention tray (2-10 liters) with working surface in phenolic resin Spill retention tray (2-10 liters) with working surface in inox steel Transparent polymethylmethacrylate rear pannel 8 mm thick (light transmission of 93%). Ideal for teaching sessions 125 V / 50 Hz Dräger pump with reactive colorimetric tubes (pack 10u) MAIN STRUCTURE Metal parts: base frame, rear wall and head 1.2 mm galvanized coated steel with anti acid polymer resin powder heat-hardened at 200 °C Transparent polymethylmethacrylate 6 mm thick (light transmission of 93%) Front and side panels 109 109 147 163 163 222 600 550 279 600 576 600 587 556 620 390 75 135 600 937 Vitrina CRUMA 670 PF_G Escala: 1:10 VISTAS 670- rev.: 09 109 109 147 163 163 222 600 550 279 600 576 600 587 556 620 390 75 135 600 937 Vitrina CRUMA 670 PF_G Escala: 1:10 VISTAS 670- rev.: 09
MODULAR FILTRATION COLUMN FOR GASES AND PARTICLES (according to NFX 15-211:2009) CLASE 2 Type G Handling of liquid compounds/products FILTRATION COLUMN FOR POWDERS Molecular Filter HEPA-H14 Filter Type GS Handling of liquid and particles compounds/ products Fan Type D Handling of powder compounds DUCTLESS FUME HOOD FILTER TYPES Type A Type K Type F Type BE Type D Type ABEK For organic vapors such as ketones, ethers, alcohols, xylenes ... Eventually it can be used for inorganic acids, but only if used in small quantities because this activated carbon is not impregnated and the excess of acid vapors could saturate it quickly. For NH3 vapors and amines; also good for other organic compounds. Carbon with metal salt complexes impregnation. For formaldehyde vapors and derivatives; also good for other organic compounds. Carbon impregnated with Cu leads, so that it should never be used with inorganic acid vapors. For inorganic acid vapors as H2SO4, HCl, HNO3, and volatile sulfur compounds such as H2S, SO3, ... It can be used with organic vapors because the activated carbon incorporates impregnation of metal compounds and neutralizing salts. It is also suitable to filter organic and inorganic compounds when they are in similar proportions. HEPA H-14 filter (High Efficiency Particulate Air, according to EN-1822: 1998) for filtering dust and smoke particles. Mixed type to be used when the ratios between organic, inorganic and NH3/amines are similar. ACCORDING TO STANDARDS Cabinets / Fume Hoods Filters Quality AFNOR NF X 15-211:2009 (France) BS 7258: 94 (UK) BS 7989: 2001 (UK) ANSI/ASHRAE 110-1995 (USA) CSA Z 316.5-94 (Canada) EN-779: 1996 (HEPA & ULPA Filters) EN-1822:1998 (HEPA & ULPA Filters) EN-141:2001 (Gas Filters) UNE EN ISO 9001:2008 Information storage and interaction with the alarm system. Filters with microchip and USB connection, intelligent filtering www.cruma.es export@cruma.es we recognise our responsibility and dependence towards a healthy environment and, therefore, donate 1% of our annual sales to environmental organisations around the world. A. Canals
DISTRIBUTED BY: Pol. Ind. Estruch - Carrer Moreres, 51 - 08820 El Prat de Llobregat - Barcelona T. +34 93 370 61 62 - export@cruma.es - www.cruma.es &
This model is perfect to be joined to another hood of similar measures or to a CRUMA 990. Ideal to remove from the working area gaseous polluting agents and/or solid particles/ aerosols in a simple, efficient and cost effective way, protecting both the user and the environment. CRUMA 870 ductless fume hood uses the CRUMA filtration system. Cruma ductless fume hoods designed to handle low toxic products are made of steel plate with antiacid polymerized epoxy coating and methylpropileno of high resistance. PROTECTION OF AND RESPECT FOR THE ENVIRONMENT –The toxic chemical products are not released outside but retained within the filter. COST SAVINGS AND FAST SET UP –No building work is needed to install ducts to channel the gas outside, which means fewer problems for a laboratory working at full capacity. FLEXIBLE –It can be used in areas where it is difficult to remove/extract contaminated air, such as from the lower levels in buildings that have a number of floors. ENERGY SAVINGS –The air that is sucked in is not expelled but recirculated back into the lab after the contaminating substances have been removed. This means that it is not necessary to increase the use of the air-conditioning or heating systems to compensate for the air removed. CERTIFIED –Manufactured in Spain and certified by an external laboratory according to international standards and applying the criteria of ISO 9001. 1 1 to 2 1 175 m3/h 0,50 m/s 0,287 m3 10,2 91 W 110-220 V - 50-60 Hz 18 W / 900 Lux 48 dB 0,42 m3 77 Kg USES General chemistry involving small volumes of reagents or chemical compounds at ambient/moderate temperature in all types of laboratories: √ Research laboratories √ Quality control laboratories √ Clinical and hospital laboratories √ University and school laboratories …In general, in any kind of laboratory. NEW FEATURES DUCTLESS FUME HOOD More information on the new LCD display √ New size 127x34mm display √ Air speed continuously monitored √ Type of filter installed, working hours, expiration date and next revision date √ Open door warning through electronic photocell √ Countdown timer √ Clock and calendar New features and components √ Initial air flow cycle adequacy and final purge cycle √ Fault LED √ Control of air flow through Microprocessor √ Activated carbon filters with electronic chip √ LED illumination New alarms and scheduled warnings √ Open door warning √ Open door in off mode warning √ 60h of filter use warning √ Next validation warning √ Few hours of filter life warning √ Countdown timer warning √ Expired filter alarm (by hours) √ Expired filter alarm (by date) √ Temperature alarm √ Equipment without filter alarm √ Low barrier alarm TECHNICAL FEATURES Number of filtration columns Number of filters Number of IP44 fans Average volume of treated air Average face velocity Internal volume of the cabinet Renewals inside the cabinet / min Total electrical power consumption Voltage-Frequency LED light intensity Noise level Packaging: 100% recycled wooden box with international phytosanitary certificate Volume Weight www.cruma.es export@cruma.es Because we are convinced of the quality of our products. It is not a typographical error, 7 year warranty 7 Well done, well shipped. Our responsible packaging Wood box 100% recyclable with international phytosanitary certificate. *More information www.cruma.es Do you need help or technical assistance? Contact your distributor or call us if you have any questions or need technical support, spare parts, maintenance service... +34 93 370 61 62 SIZES (MM) External Internal Width Depth Height Width Depth Height 800 776 600 566 1037 720
SIZES (MM) 800 750 261 136 136 203 203 147 329 800 776 800 597 566 390 720 75 135 600 1037 Vitrina CRUMA 870 PF-G Escala: 1:10 VISTAS 870- rev.: 09 800 750 261 136 136 203 203 147 329 800 776 800 597 566 390 720 75 135 600 1037 Vitrina CRUMA 870 PF-G Escala: 1:10 VISTAS 870- rev.: 09 DUCTLESS FUME HOOD SERIAL EQUIPMENT Electronic circuit with large format LCD screen Electronic anemometer device Photocell sensor device for open door detection Electronic control device for filters replacement Illumination Sampling system to analize the filtered air at the exhaust 60 hours alarm Electronic cronometre with audible alarm Clock and calendar Working surface 1 G4 Prefilter Cable entry holes (2) Chemical Listing Warranty Security levels: level 1 for users and level 2 for maintenance users Electronic sensor monitoring continuously air face velocity Electric device with open door alarm The filters incorporate a microchip with miniUSB connection that identifies the type of filter installed, the expiry date and the serial no. 96 LED Tube high light intensity and low power consumption - 16 Watts / 700 Lux To detect the level of filter saturation Countdown timer according to French NF X 15-211:2009 To program the work inside the fume hood Display of date and time Spill retention tray (2-10 liters) with working surface in white tempered glass G4 class pre-filtering blanket of synthetic biofibres (according to EN-779) for the retention of atmospheric dust Access to the rear wall for cables and / or services entry Guide of retained products by type of filter 7 years OPTIONAL EQUIPMENT Movilair Tubular steel stand Working surface 2 Working surface 3 Transparent rear back pannel Voltage / Frequency Filter test kit Stand with wheels and internal tray in Epoxy coated steel Support stand in Epoxy coated steel Spill retention tray (2-10 liters) with working surface in phenolic resin Spill retention tray (2-10 liters) with working surface in inox steel Transparent polymethylmethacrylate rear pannel 8 mm thick (light transmission of 93%). Ideal for teaching sessions 125 V / 50 Hz Dräger pump with reactive colorimetric tubes (pack 10u) MAIN STRUCTURE Metal parts: base frame, rear wall and head 1.2 mm galvanized coated steel with anti acid polymer resin powder heat-hardened at 200 °C Transparent polymethylmethacrylate 6 mm thick (light transmission of 93%) Front and side panels
