PRODUCT C A T A L O G 2025 SUTO | Be smart. Measure it. ULPA Clean rooms & Laboratories
אודות החברה משווקת ציוד ULPA Clean Rooms & Laboratories חברת SUTO בדיקה ומכשור מתקדם למערכות אוויר דחוס מתוצרת חברת הגרמנית. הציוד כולל: חיישנים למדידת לחות, טמפרטורה ולחץ: לניטור תנאי מערכות האוויר הדחוס. מדי ספיקה וצריכה: לניהול יעיל של צריכת אוויר דחוס והפחתת עלויות וחסכון באנרגיה. מכשירי זיהוי חלקיקים: לאיתור זיהומים באוויר דחוס, בהתאם .ISO 8573 לתקני מערכות ניטור און-ליין: מאפשרות ניטור רציף ושמירה על איכות האוויר בתהליכים קריטיים. לספק פתרונות ULPA- מאפשר ל SUTO שיתוף הפעולה עם אמינים ומדויקים לשיפור היעילות, הבקרה ואיכות האוויר הדחוס בתעשיות מגוונות.
1/16 Product Overview 2025 www.suto-itec.com Be smart. Measure it. Measurement Technology for Compressed Air, Gases and Liquids
2/16 Generation S211 S215 S220 S430 Modbus/RTU Treatment External Air Quality Advanced Measurement Solutions Compressed Air and Gas Monitoring - get your system under control The use of compressed air and technical gases in modern production processes has become indispensable. Compressed air is used to drive actuators, machines and to control other automated processes. Technical gases and air are used to conserve food or are even becoming part of the product, like in the beverage production. SUTO iTEC is a leader and trusted global partner for reliable measurement and monitoring solutions for compressed air and gas systems. Our wide range of products play a vital role in processes of leading companies around the world ensuring system reliability and efficiency. S531 S520 S110 Power Meter Leakage Spot Checking Dew Point Spot Checking S601 Power On/O S305 S532 S600 S305 Dew Point Monitor ! Pmax: 1.5 MPa Back Enter System Performance and Reliability Energy Efficiency and Cost Reduction Product Quality and Safety ISO Standard Compliance
3/16 Power S330 S331 S401 Distribution Point-Of-Use S4M SaaS S415 S418 Modbus/RTU Outdoor/Ex S451 S453 Liquids S461 Breathing Air S606 S462 Breathing Air Liquid Rec. Stat. cfm psi Rec. Stat. cfm psi Flow Meter Flow Meter Power On/O Data Logging Data Analysis S605 S415 S418 S421 Power Ultrasonic Transducer Item No.: S695 4610 Model: UT-S Rating: IP68/0...+80ºC www.suto-itec.com Flow Ultrasonic Transducer Item No.: S695 4610 Model: UT-S Rating: IP68/0...+80ºC www.suto-itec.com Flow Be smart. Measure it. Modbus/RTU
Be smart. Measure it. 4/16 Installation In-line type with measuring section DN15 to DN80 (Thread / Flange) Thermal Mass Flow Meter S401 Insertion S421 In-line Installation Insertion type DN25 to DN1000, installation under pressure through 1/2” ball valve Pitot Tube Flow Meter for Wet Air S430 Insertion S421 S421 Application • Flow and velocity monitoring of the compressor outlet • High temperature flow applications • Compressor efficiency testing with S551 Portable Data Logger and S110 Power Meter Flow and Consumption Meters for Compressed Air and Gases Thermal Mass Flow Meter Application • Non-intrusive solution to measure compressed air and gas consumption and flow in main and distribution lines • Applications in a wide range of industries, helping with energy management, process control, cost allocation and quality assurance Signal Outputs • Isolated 4 ... 20 mA & Pulse • Modbus/RTU • Modbus/TCP • M-Bus Signal Outputs • Isolated 4 ... 20 mA & Pulse • Modbus/RTU • Modbus/TCP • M-Bus Application • Efficient solution to measure compressed air and gas consumption and flow in main and distribution lines • Applications in various industries, aiding in energy management, process control, cost allocation and quality assurance Signal Outputs • Isolated 4 ... 20 mA & Pulse • Modbus/RTU • Modbus/TCP • M-Bus Fast response time for accurate results Easy and efficient monitoring Mobile app for remote configuration Wet air measurement at the compressor outlet See info sheet Compressor S430 Generation Distribution Distribution See info sheet Easy Installation through 1/2” ball valve under pressure Mobile app for remote configuration Reliable total flow measurements Cost-efficient and affordable sensor solution Power Receiver Tank S401 Easy Installation with pre-assembled measuring section Mobile app for remote configuration Reliable total flow measurements IP65 Casing provides robust protection See info sheet Installation Insertion type for pipe sizes of DN32 to DN1000 installation under pressure through 3/4” ball valve
5/16 Be smart. Measure it. Compact Thermal Mass Flow Meter S415 Economic S418 High End S418-V Vacuum S415 S415 Rec. Stat. cfm psi Rec. Stat. cfm psi Rec. Stat. cfm psi Rec. Stat. cfm psi Rec. Stat. cfm psi Compressed Air CO2 N2 Argon O2 Application • Low cost and broad monitoring of general processes • Compressed air flow and consumption monitoring of individual machines and processes to improve efficiency and reliability Application • Performance monitoring of vacuum pumps. • Monitoring of critical values in vacuum applications which help operators to ensure the process reliability. Application Accurate compressed air and gas flow monitoring, to discover weak points in the process flow, thus ensuring continuity and profitability. Installation In-line type: G inner thread connection - DN8, DN15, DN20, DN25 or DN32 (ISO 228-1) S418 Installation In-line type: G inner thread connection - DN8, DN15, DN20, DN25 or DN32 (ISO 228-1) Flow and Consumption Meters for Compressed Air and Gases Compact Thermal Mass Flow Meter Installation In-line type: G inner thread connection - DN8, DN15, DN20, DN25 or DN32 (ISO 228-1) Compact Thermal Mass Flow Meter Signal Outputs • Isolated 4 ... 20 mA & Pulse • Modbus/RTU • M-Bus Signal Outputs • Isolated 4 ... 20 mA & Pulse • Modbus/RTU • M-Bus Signal Outputs • Isolated 4 ... 20 mA & Pulse • Modbus/RTU • M-Bus Rec. Stat. cfm psi Rec. Stat. cfm psi Cost-efficient and affordable sensor solution Data logger for measurement data recording Vacuum flow with absolute pressure sensor integrated Compact design for easy and flexible installation Total mass flow: No bypass measurement needed Accurate Results thanks to integrated flow conditioner Flow conditioner: no straight inlet required Compact design for easy and flexible installation Compact design for easy and flexible installation Point-of-use monitoring of compressed air and nitrogen Point-of-use monitoring of machines and consumers Point-of-use monitoring of vacuum pumps See info sheet See info sheet See info sheet Point-of-Use Point-of-Use Point-of-Use S418-V Rec. Stat. cfm psi Vacuum User 6.2bar Vacuum Pump
Be smart. Measure it. 6/16 Flow and Consumption Meters for Compressed Air and Gases S409 Insertion Thermal Mass Flow Meter for Heavy Duty and Ex Applications Thermal Mass Flow Direction Switch Insertion In-line S451 S453 Thermal Mass Flow Meter for Heavy Duty and Ex Applications Installation Insertion type DN25 to DN1000, installation under pressure through 3/4” ball valve Application • Outdoor / all-weather flow applications • Explosive environments • Cost overview for gas consumption within the distribution network S451 S453 Signal Outputs • 2 x 4 ... 20 mA, pulse & Modbus/RTU • 2 x 4 ... 20 mA, pulse & Ethernet/APL (Modbus/TCP protocol) Installation Inline type flow meter with measuring sections from DN25 to DN80 (R-thread / Flange) Application • Outdoor / allweather flow applications • Explosive environments • Cost overview for gas consumption within the distribution network Signal Outputs • 2 x 4... 20 mA, pulse & Modbus/RTU • 2 x 4... 20 mA, pulse & Ethernet/APL (Modbus/TCP protocol) Installation Insertion type DN25 to DN1000, installation under pressure through 1/2” ball valve Application • Flow direction switch for reliable indication of flow directions. Flow-Switch can be connected to bidirectional flow meters for direction detection. • Two separate relays for direction indication Signal Outputs • Relay for forward • Relay for reverse S409 Outdoor and Ex Outdoor and Ex Multiple Locations Easy Cleaning: All wetted parts stainless steel Easy Installation with pre-assembled measuring section Supply via flow sensor for minimal effort Explosion proof for use in Ex-area applications Explosion proof for use in Ex-area applications Reliable direction detection Pressure and temperature independence Accurate results and fast response time Cost-efficient and affordable sensor Industrial design for harsh environments Industrial design for harsh environments Non-intrusive solution for easy installation See info sheet See info sheet See info sheet
7/16 Be smart. Measure it. Dew Point Meters for Compressed Air and Gases -60 ... +20 ºC Td -20 ... +50 ºC Td -100 ... +20 ºC Td S211 S215 S220 Dew Point Sensor Dew Point Sensor Dew Point Sensor Installation G1/2” Process connection for installation directly in process or via measuring chambers. Application Dew point measurements after desiccant dryers Desiccant Dryer Fridge Dryer Desiccant Dryer Measured Gases Air / CO₂ / N₂ / O₂ / Argon Operating pressure • 0 ... 1.6 MPa • Optional 35.0 MPa Signal Outputs • 4 ... 20 mA 2-wire + SDI • 4 ... 20 mA 3-wire + SDI • 4 ... 20 mA 3-wire + Modbus/RTU Optional Display Installation G1/2” Process connection for installation directly in process or via measuring chambers. Application Dew point measurements after fridge dryers Measured Gases Air / CO₂ / N₂ / O₂ / Argon Operating pressure • 0 ... 1.6 MPa • Optional 35.0 MPa Signal Outputs • 4 ... 20 mA 2-wire + SDI • 4 ... 20 mA 3-wire + SDI • 4 ... 20 mA 3-wire + Modbus/RTU Installation G1/2” Process connection for installation directly in process or via measuring chambers. Application Dew point measurements in high tech requirements and conditions Measured Gases Air / CO₂ / N₂ / O₂ / Argon Operating pressure 0 ... 1.6 MPa Signal Outputs • 4 ... 20 mA 2-wire + SDI • 4 ... 20 mA 3-wire + SDI • 4 ... 20 mA 3-wire + Modbus/RTU S211 S215 S220 Optional Display Optional Display Treatment Treatment Treatment -60 ... +20 ºC Td After desiccant dryers -20 ... +50 ºC Td After fridge dryers -100 ... +20 ºC Td for high tech applications Integrated pressure sensor (option) Integrated pressure sensor (option) Compressed Air Quality Monitoring Long term stable for low maintenance costs High Precision ± 2 °C Td Accuracy Precise and stable measurement (± 2 °C Td Accuracy) Compact design for installation anywhere Compact design for easy and flexible installation Dual sensor solution (QCM + polymer) for high accuracy See info sheet See info sheet See info sheet
Be smart. Measure it. 8/16 Dew Point Monitor Dew Point Transmitter for Ex Applications Portable Dew Point Meter S230 -100 ... +20 ºC Td S231 -50 ... +20 ºC Td -100 ... +20 ºC Td -60 ... +20 ºC Td -20 ... +50 ºC Td S520 S305 -60 ... +50 °C Td Dew Point Meters for Compressed Air and Gases Installation G1/2” Process connection for installation directly in process or via measuring chambers. Installation Point-of-use spot checking with easy process connection via 6 mm quick connect Installation Stationary Installation easy process connection via 6 mm quick connect Application • Dew point measurement in explosive environments • Outdoor / All-weather dew point measurement applications Application • ISO 8573-1 dew point audits • Dew point checks at the point of use • Drier performance checks • Measure absolute humidity in units like ppm or mg/m³ Application • Monitor fridge and desiccant driers • Simple after market installation • Process humidity monitoring and notification in case of alarms Measured Gases Air / CO₂ / N₂ / O₂ / Argon Measured Gases Air / CO₂ / N₂ / O₂ / Argon Measured Gases Air / CO₂ / N₂ / O₂ / Argon Operating pressure • -0.1 ... 1.6 MPa (S230) • -0.1 ... 35 MPa (S231) Operating pressure -0.1 ... 1.5 MPa(g) (at least 0.3 MPa is needed for the measuring chamber supplied with the instrument) Operating pressure 0.3 ... 1.5 MPa Signal Outputs • 4 ... 20 mA (isolated) • Modbus/RTU Signal Outputs • Internal data logger • On site print outs • USB interface for data transfer Signal Outputs 4 ... 20 mA 3-wire S305 Dew Point Monitor ! Pmax: 1.5 MPa Back Enter Fridge and Desiccant Dryer S230 S231 S305 S520 Low dew point measures down to -100 °C Td Alarm indication with internal relays or alarm units Flexible dew point meter for on-site live data Industrial design for rough environment -60 ... +50 °C Td Range depending on model Low dew point, down to -100 °C Td Explosion proof for use in Ex-area applications Plug & Play solution for simple and fast connection Smart device with dew point prediction See info sheet See info sheet See info sheet Dual sensor system for full range precision Fast response time for efficient monitoring Dew point audits according to ISO 8573-1 Outdoor and Ex Dryer Monitoring Mobile Measurements
9/16 Be smart. Measure it. Air Quality Instruments for Compressed Air and Gases Laser Particle Counter Oil Vapor Monitor Portable Compressed Air Purity Analyzer S130 ECO (0.3 < d ≤ 5.0 µm) Display & Data Logger S132 PRO (0.1 < d ≤ 5.0 µm) 5 in 1 Plug & Play S120 S600 Application Permanent monitoring of oil content in compressed air and gas systems to ensure crucial processes in: • Medical and pharma industry, • Food and beverage, • Semiconductor fabs • High tech applications Application • Air quality measurements in medical, pharmaceutical, food and beverage and other applications • Compressed air quality audits in regards to the ISO 8573-1 • Monitoring of high tech applications with strict air purity requirements Application • Permanent participle measurement and monitoring of compressed air and gases in high tech applications. • Fulfilling requirements according to compressed air standard ISO 8573-4. Measured Gases Compressed Air, Nitrogen N₂, Carbon dioxide CO₂ (software setting) Pressure Range • 0.3 ... 1.5 MPa • 600 ... 1070 hPa abs. (Ambient version only) Signal Outputs • 4 ... 20 mA (isolated) • Modbus/RTU • Modbus/TCP (available for display version) • Alarm Relay: NO, 40 VDC, 0.2 A • USB Measured Gases Compressed Air, Nitrogen N₂, Carbon dioxide CO₂ (software setting) Pressure Range 0.3 ... 1.5 MPa Signal Outputs • Modbus/RTU • Modbus/TCP • USB • 4G/LTE Modem (optional) Measured Gases Compressed Air, Nitrogen N₂, Carbon dioxide CO₂ (software setting) Pressure Range 0.3 ... 1.5 MPa Signal Outputs • Modbus/RTU • Alarm Relay: NO, 40 VDC, 0.2 A • USB Installation Easy process connection via 6 mm quick connect Installation Easy process connection via 6 mm quick connect Installation Easy process connection via 6 mm quick connect S600 S130 / S132 Read instruction Manual before use CB A S130 Laser Particle Counter Power Service Counting ! Receiver Tank S120 CB A Inlet S120 Oil Vapor Analyzer Power Service Service Sensor Service Filter Read instruction Manual before use ! Receiver Tank Latest PID sensor technology for fast response time Plug & Play solution for easy installation Software guided measurement for high precision Data logger to store values Pro Version S132 Smallest channel 0.1 < d ≤ 0.5 μm Ultra-portable and compact design Plug & Play oil vapor monitoring solution Particle measurement according ISO 8573 All in one solution: dew point, particle and oil vapor See info sheet See info sheet See info sheet Dew Point Sensor Option: -100 ... +20 °C Td Eco Version S130 Smallest channel 0.3 < d ≤ 0.5 µm PDF Report generator for ISO 8573-1 audits Point-of-use Point-of-use Mobile Measurements
10/16 Be smart. Measure it. Stationary Compressed Air Purity Monitor Portable Breathing Air Analyzer Stationary Breathing Air Monitor 5 in 1 Plug & Play S601 5 in 1 Plug & Play 6 in 1 Plug & Play S606 S605 Air Quality Instruments for Compressed Air and Gases Application • Permanent measurement and monitoring of compressed air quality in high tech applications with strict purity requirements, such as medical air, pharmaceuticals, food and beverage, etc. • Ensuring compressed air quality standards as stated in ISO 8573-1. Application • Regular checks of breathing air systems in various sectors as fire fighting, diving, spray painting, chemical industry, offshore and high tech applications. • Meeting requirements of international standards such as EN 12021 or CFR 1910.134(d). Application • Permanent monitoring of breathing air systems and filling stations for crucial industries and sectors like fire fighting, diving, spray painting, chemical industry, offshore and high tech applications. • Meeting requirements of international standards such as EN 12021 or CFR 1910.134(d). Measured Gases Air / CO₂ / N₂ / O₂ / Argon Measured Gases Breathing air gases Measured Gases Breathing air gases Pressure Range 0.3 ... 1.5 MPa Inlet Pressure 3 ... 15 barg, External pressure reducer allow up to 350 bar process pressure Inlet Pressure 3 ... 15 barg, External pressure reducer allow up to 350 bar process pressure Signal Outputs • Modbus/RTU (RS485) • Modbus/TCP (Ethernet) • USB Signal Outputs • Modbus/RTU (RS485) • Modbus/TCP (Ethernet) • USB • 4G/LTE Modem (optional) Signal Outputs • Modbus/RTU (RS485) • Modbus/TCP (Ethernet) • USB Installation Robust wall mountable cabinet with 6 mm hose connection Installation Easy-to-carry case with easy process connection via 6 mm quick connect Installation Wall mountable cabinet with 6 mm hose connection S601 S605 Compressor S606 Reserve Air System 24/7 compressed air quality and purity monitoring Plug & Play with simple and fast connection Permanent monitoring with alarm information Integrated data Logger for online monitoring Ultra-portable and compact design Single gas inlet for a convenient setup All-in-one solution to measure ISO 8573-1 parameters All in One: O₂, CO₂, CO, H₂O, Oil, Pressure All in One: O₂, CO₂, CO, H₂O, Oil, Pressure See info sheet See info sheet See info sheet Plug & Play operation, no configuration Powerful PDF breathing air report generator Robust metal cabinet for rough environments Treatment Point-of-use Generation
Be smart. Measure it. 11/16 Leak Detection for Compressed Air and Gases Smart Ultrasonic Leak Detector (for Compressed Air, Gas and Pneumatic Systems) Ultrasonic Leak Detector (for Compressed Air, Gas and Pneumatic Systems) Leak Management Software S531 Portable S530 Portable LMS Local Installation Application Leak detection in compressed air or gas systems such as refrigerators • Ultrasonic • With focus tube and focus tip • Integrated laser pointer Features The S531 helps users quickly locate and record leaks in compressed air, gas and pneumatic systems. • Ultrasonic Technology • With focus tube and focus tip • Integrated laser pointer • Trumpet, to focus the sound waves Benefits • Easy to use handheld device for simple leak surveys. • Identifies leaks in compressed air systems which helps to save energy and reduce compressed air costs Application The Leak Management Software (LMS) enables companies to properly manage their leakage detection and repair activities. The LMS works seamlessly with the S531 and S532 leak detectors. Detect leaks in the field with the S531/S532 and later import them into the LMS software for quantitative leakage data and powerful reporting. Installation Local installation for easy setup and local data storage Free LMS License Laser pointer for quick spot leak detection Big memory for leak records, photos and voice recording Compact design for flexible usage Integrated camera for leak photos Easy to use solution to find leaks in minutes Leak detection even from distance See info sheet See info sheet See info sheet Noise isolated headset for inaudible signals Data analysis and loss calculation Free LMS License Application Easy-to-use handheld device identifies leaks in compressed air and gas systems, helping to save energy and reduce compressed air costs Acoustic Leak Camera (for Compressed Air, Gas, Pneumatic Systems and Partial Discharge) S532 Portable See info sheet Realtime leak visualization Built-in camera for leak photos Detects leaks up to 150 meters Data analysis and loss calculation S531/S532 LMS + Application • Compressed Air Systems: Detects and manages leaks. • High Voltage Systems: Identifies partial discharges. • Industrial Maintenance: Streamlines detection and recording. Features • 64 low-noise MEMS microphones • 4.3” LCD touch screen with visual overlay • Adjustable frequency range from 0 kHz to 96 kHz • 64 GB SD card for 20,000 images and 60 hours of video • Integrates with SUTO Leak Management Software (LMS)
Be smart. Measure it. 12/16 Ultrasonic Flow Meter for Liquids Flow and Consumption Meters for Liquids and Steam Compact Ultrasonic Flow Meter for Liquids Vortex Flow Meter for Steam Clamp-On S461 S462 Clamp-On S435 In-Line Application Actual flow and total consumption monitoring in: • Cooling / Heating / Process Water • Purified Water Measurement • Fuel, Oils, Petroleum Products • Water Treatment • Food / Beverage • Sanitary • Hydraulic System Test • Pharmaceutical Industry Application Clean fluid measurements in: • Cooling / Heating / Process Water • Purified Water Measurement • Fuel, Oils, Petroleum Products • Water Treatment • Food / Beverage • Sanitary • Hydraulic System Test • Pharmaceutical Industry Application • Measures the saturated steam flow and consumption to ensure the process quality. • The integrated consumption counter allows to calculate steam usage for each consumer in the system. Installation Clamp-On Installation for pipe sizes of DN40 ... DN1200, Versatile installation options for the display unit Installation • Clamp-On for pipe sizes of DN20 ... DN40 • Can be installed on stainless steel pipe, carbon steel pipe, copper pipe or plastic pipe. Installation Intermediate flange installation for pipe sizes from DN40 ... DN300 Signal Outputs • Isolated 4 ... 20 mA (Analog option) • Switch output, normally open, max. 40 VDC, 0,5 A (Pulse option) • Modbus/RTU(Standard) • Modbus/TCP and PoE (Option) Signal Outputs • Isolated 4 ... 20 mA (Analog) • Modbus/RTU Signal Outputs • 4 ... 20 mA • Pulse • Modbus/RTU S462 Ultrasonic Transducer Item No.: S695 4610 Model: UT-S Rating: IP68/0...+80ºC www.suto-itec.com Flow Ultrasonic Transducer Item No.: S695 4610 Model: UT-S Rating: IP68/0...+80ºC www.suto-itec.com Flow Power S461 S435 UP 000.00 01 V m3/h T004799.734 DOWN Smartphone app for easy configuration Local display for easy configuration and live values Advanced Transit Time Correlation Technology Energy Meter Monitors heat exchangers Vortex flow measurement for accurate results Cost-efficient and affordable sensor solution Non-Invasive through clampon sensors Effective and inexpensive measurements Clamp On: No contact to medium See info sheet See info sheet See info sheet Easy installation Various installation options anywhere Temperature sensor with automatic density adjustment Stationary: Connectable to S330/S331 Multiple Locations Multiple Locations Steam Pipes
13/16 Be smart. Measure it. Displays / Data Logger and IIoT for Data Logging and Visualization Display and Data Logger Display for Sensors Portable Display and Data Logger S320 Local installation S551 Portable S330 S331 Display Application Convenient data reading from difficult-to-access sensors. Application Central unit of a compressed air monitoring system displaying and recording all relevant parameters in a compressed air system (Flow, consumption, dew point, pressure, temperature, power consumption, compressor status etc.). Application • The ideal data logger for energy analysis (ISO 50001) and air audits (ISO 11011). • Compressor efficiency testing Installation • Panel mounting (standard) • Wall mounting • Hat rail holder (only in connection with wall mounting casing) Installation • Panel mounting (standard) • Wall mounting Installation Portable solution: Carrying case for a flexible and efficient usage at the point-of-use Sensor Inputs • 1 input for SUTO flow/ dew point sensor • 1 input for analog sensor 0 ... 20 mA, 0 ... 10 V Sensor Inputs Up to 20 sensors inputs: • 2 x SDI • 2 x analog • 16 x Modbus Outputs • Modbus/TCP (Ethernet) • Modbus/RTU (RS 485) • USB • 2 Alarm relay outputs Inputs 2 digital inputs: • SDI Sensors (up to 2 SDI sensors) • Modbus Sensors (up to 16 Modbus sensors) 2 analog inputs (option): • 0 ... 20 mA, 4 ... 20 mA • 0 ... 10 V • Pulse S320 11 12 13 Modbus / RTU m³/h, MPa, °C S551 M Modbus sensor M 3 A MPa ˚C MPa ˚C 1 ˚Ctd A ˚Ctd 4 2 Modbus sensor Compressor Data Visualization Data Logging Multiple Locations USB Interface Configuration with S4C software Versatile connection with 16 sensors inputs Versatile connection with 20 sensors inputs Alarm function with optional alarm settings Large 5” color LCD touch screen 4G/LTE Modem (optional) for remote monitoring and logging User-friendly design for easy usage IIoT Support: Connection to S4M software Auto detection of SDI or Modbus SUTO sensors See info sheet See info sheet See info sheet Signal digital and analog inputs Data Logger with 100 million values Large 5” color LCD touch screen Receiver Tank Compact Data Logger Flex
Be smart. Measure it. 14/16 Smart Compressed Air System Monitoring Software Monitoring and Application Software and Apps Free Mobile Apps S4C-FS Gas Flow S4C-DP S4C-US Dew Point Liquid Flow S4M SaaS Cloud Applications • SUTO Smartphone Apps are free to use. • Wireless real-time data readings with S4C-FS App. • User-friendly design and intuitive workflows. • Operate entirely from your smartphone. • Online configuration, settings, and user calibrations for SUTO devices. Signal Outputs • Wireless connection from smartphone to SUTO Sensors • No PC needed Data Analysis Software S4A Local Ethernet LAN, 4G Benefits All-in-one monitoring solution for compressed air systems. The powerful software features helps users to get their compressed air system under control Local Clients S4M SaaS Cloud Service Service Company Download The S4A Software is offered for free and the latest version can be downloaded from the SUTO iTEC homepage, no registration or subscription needed. www.suto-itec.com Sensor Input Ethernet LAN, WLAN, 4G Remote Office Location Sensor Input Monitoring, Visualization and Analysis Data Visualization and Analysis Data Visualization and Configuration Extensive Data Analysis Customer and Location Management Alarms & Notifications Powerful Report Module Process Value Visualization See info sheet Analysis on Exported Files (.XLSX and .CSV) User-friendly design for easy usage Readout of screenshots from SUTO S331 Online reading of live measurement data Powerful graphic analysis Free smartphone app for remote configuration See info sheet See info sheet Online reading via USB, Ethernet or WLAN connection Wireless connection to devices in hardto-reach places
15/16 Be smart. Measure it. Calibration and Certification Flow Dew Point Oil Vapor Calibration Calibration Calibration Instrument: S401 Serial number: 1234 5768 Item number: S695 8371 Test conditions: Test medium Air Ambient temperature: 18...26°C Test temperature: 23ºC Ambient humidity: 30...60% rH Test humidity: <30 %rH Ambient pressure: 990…1050 mbar Test pressure: 6 bar Calibration range: High speed Testing tube Di: 53.1 mm Testing method: Calibration by comparison References used: Type Model Uncertainty S/N Last Calibration Turbine Flow Meter FT-32 ± 0.50% 141119E39096 10.2021 Laminar Flow Elements LFE0 LFE1 ± 0.50% ± 0.50% 1836000032 1802000011 10.2021 10.2021 Sonic Nozzels N0-N4 ± 0.50% 831K033-37 10.2021 Calibration test results: Description Units Nominal value Permissible uncertainty Actual value Evaluation Flow m3/h 142.2 ±(1.5 % + 0.3% FS) 143.1 passed Flow m3/h 285.4 ±(1.5 % + 0.3% FS) 286.1 passed Flow m3/h 611.2 ±(1.5 % + 0.3% FS) 611.2 passed The above-mentioned calibration was performed according to SUTO iTEC working standards. Furthermore the calibration was performed by comparison with instruments, which have been calibrated at an ISO 17025 accredited calibration laboratory and is traceable to national standards. It represents the physical units according to the International System of units (SI). The reference measurement system used for this calibration has a total uncertainty of 0.65% (at confidence level: 95%) We commend that this measuring instrument should be calibrated annually. The product has been calibrated by: SUTO iTEC GmbH Grißheimer Weg 21 79423 Heitersheim Tel: +49 (0) 7634 50488-00 Fax: +49 (0) 7634 50488-19 E-mail: sales@suto-itec.com Web: www.suto-itec.com Calibration date: 28.09.2022 SUTO Inspector: F. Gleissner Signature: Page 1 of 2 Calibration certificate SUTO Calibration • SUTO iTEC owns high tech calibration facilities in Germany, Hong Kong SAR and Mainland China • Flow calibration under pressure and a wide range for highest accuracy • Real gas calibration system for technical gases • References and certificates are traceable to national standards Exchange Calibration Service Current Meter, other Sensors and Calibration Service Other Sensors Power Meter S110 Stationary S010 Pressure S110-P Portable S020 S030 Temperature Electrical Current Application The main application is to measure the power consumption and the accumulated energy consumption of electrical 3-phase consumers, like compressors, driers and oxygen/nitrogen generators. Application Industrial equipment for manifold applications • Hydraulic and pneumatic systems • Industrial engines • HVAC/R equipment • Spraying systems • Cooling systems Installation DIN rail installation for power cabinets or portable version with rugged housing Installation Easy installation in compressed air systems (for more information visit www.suto-itec.com) Signal Outputs • Isolated 4 ... 20 mA (Analog) • Modbus/RTU Signal Outputs • S010: 4 ... 20 mA • S011: Modbus/RTU • S020: 4 ... 20 mA (available in 2 sizes) • S030: 4 ... 20 mA The exchange calibration service eliminates down time and enables users to have a seamless record of their measurements. The user receives in advance a calibrated instrument with calibration certificate and the same instrument settings. The on-site instrument is then switched against the calibrated one and returned to the supplier. Compressor Rogowski Coils Generation Modbus / RTU Interface can connect to any Modbus-Master 4 ... 20 mA output connection User-friendly design and setup Cost-efficient affordable sensor solutions Multi-functional: 3-phase, 1-phase Industrial design for various applications Various Calibrations: Flow / Dew Point / Oil Vapor / Particle / Pressure/ Temperature See info sheet See info sheet See info sheet Identifying compressor efficiency Strong Protection IP65 Casing See info sheet See info sheet S010 S020 S030
NA EU HK CN China Office Shenzhen, China Europe Office Heitersheim, Germany +49 (0) 7634 50488-00 sales@suto-itec.com Asia/Pacific Office Hong Kong North America Office Grand Rapids, USA Main Offices Production, Services and Sales Sales Partner in +50 Countries www.suto-itec.com Be smart. Measure it. +86 (0) 755 8619 3164 sales.cn@suto-itec.com +852 2328 9782 sales.asia@suto-itec.com +1 (616) 800-7886 sales.us@suto-itec.com Talk to an Expert International Edition (EN) - 25-1. © 2025 SUTO iTEC GmbH. www.suto-itec.com
1/5 www.suto-itec.com Be smart. Measure it. Accessories
2/5 Accessories Order No. Description Application Picture C190 0002 Closing cap for S421/S452 material: 1.4404 To close the measuring sections in case the sensor unit is removed A695 0009 Thread adapter, G 1/2” internal to PT 1/2” external, SUS303 Used to adapt S401 or S450 to a PT thread ball valve A695 0008 Thread adapter, G 1/2” internal to NPT 1/2” external, SUS303 Used to adapt S401 or S450 to a NPT thread ball valve C190 0116 Flow conditioner Wafer type flow conditioners, which is flanged between two flanges 5-8 times diameter upstream of the flow meter. Please specify nominal pipe diameter and pressure A530 1105 / A530 1106 / A530 1111 / A530 1113 High pressure installation device. To be used for pressure > 1.5 MPa For safety reasons we recommend using this installation device whenever the operating pressure exceeds 1.5 MPa * A530 1105 - High pressure installation device for S401-220 mm * A530 1106 - High pressure installation device for S450-220 mm * A530 1111 - High pressure installation device for S401-400 mm * A530 1113 - High pressure installation device for S450-400 mm A530 1206 SUTO Spot Drilling Set for 1/2" and 3/4" access points, including 13 mm and 19 mm drills + all required accessories This drilling tool is used to drill holes into compressed air pipes under pressure through a ball valve A553 0104 Sensor cable 5 m with M12 connector, open wires, AWG 24 (0.2 mm²) 5 pole cable, used to connect sensors to display, data loggers and third-party systems A553 0105 Sensor cable 10 m with M12 connector, open wires, AWG 24 (0.2 mm²) 5 pole cable, used to connect sensors to display, data loggers and third-party systems A553 0146 Sensor cable 5 m with M12 and RJ45 connectors, PoE supported, AWG 24 (0.2 mm²) Used to connect SUTO flow sensor with Modbus/TCP to the local network. A553 0161 M8 female to M12 male converter cable Used to connect the S415/S418 to a Modbus/RTU splitter Ordering Please use the following table to assist in placing your order with our sales staff.
3/5 Accessories Order No. Description Application Picture A553 0165 Sensor cable, 5 pole, AWG 24 (0.2 mm²), 50 m Used to connect sensors and devices to gateways, power supplies and PLCs A553 0166 Sensor cable, 5 pole, AWG 24 (0.2 mm²), 100 m Used to connect sensors and devices to gateways, power supplies and PLCs A553 0167 RS-485 cable, 4 pole twisted pairs, AWG 24 (0.2 mm²), 50 m Used to connect sensors and devices to Modbus Masters A553 0168 RS-485 cable, 4 pole twisted pairs, AWG 24 (0.2 mm²), 100 m Used to connect sensors and devices to Modbus Masters A554 0009 Power supply, DIN rail, Input 85 ... 264 VAC, output: 24 VDC / 60 Watt This power supply is used to supply sensors with 24 VDC / 2.5 A DIN rail installation. A554 0007 Power supply, wall-mountable, Input 85... 264 VAC, output: 24 VDC / 15 Watt This power supply is used to supply sensors with 24 VDC / 0.6 A Wall mountable casing. A554 0008 Ball valve, G1/2”, full pass-through This ball valve is used to install insertion type flow sensors with a G1/2” connection. P554 0009 Wall thickness meter The instrument is used to measure the wall thickness of pipes. Too often the inner diameter of pipes is not exactly known, but this information is required for an accurate flow measurement. By measuring the wall thickness and the pipe size the exact inner diameter can be calculated A554 0107 Mains unit 100-240 VAC/24 VDC, 0.5 A for M12-sensors, 1.5 m cable Simple power supply for M12 sensors with 24 VDC A554 2005 Service kit for sensor configuration including software This service kit can be used for all SUTO sensors to change settings and check sensors C190 0594 G1/2” inner thread for flow sensor, G1/4” inner thread for pressure sensor, R1/2” external thread to process connection (ball valve) Thread adapter to combine S401 flow sensor with pressure sensor in one access point. Ordering Please use the following table to assist in placing your order with our sales staff.
4/5 Accessories Order No. Description Application Picture A699 3491 Measuring chamber, 2 l/min @ 0.8 MPa, fast connector, without filter, max pressure 1.5 MPa(g), suitable for all SUTO dew point sensors For easy connection and disconnection to compressed air system through quick-disconnector A699 3492 Measuring chamber, 2 l/min @ 0.8 MPa, 6 mm hose quick connector, without filter, max. pressure 1.5 MPa(g), suitable for all SUTO dew point sensors For easy connection and disconnection to compressed air system through quick-disconnector A699 3493 By-pass-type chamber with 6 mm hose in and out connection up to 1.5 MPa(g) This chamber can be used in applications where the measured gas is by-passed through the chamber A699 3500 Measuring chamber, 4 l/min @ 0.8 MPa, hose fast connector, with filter, recommended pressure range 0.3 ... 1.5 MPa, convenient dew point measurement of gas/air with SUTO portable dew point meters The sample gas/air is connected to the chamber through a 6 mm Teflon® hose The chamber is mounted to the SUTO portable dew point meters through the 1/2“ G-type thread connection. Parking and measurement position is selected through the handle at the chamber, which allows quick measurement results A699 3501 By-pass-type chamber with 6 mm hose in and out connection up to 1 MPa, convenient dew point measurement of gas/air with SUTO portable dew point meters This chamber can be used in applications where the measured gas is by-passed through the chamber to avoid any gas/air loss. The chamber is mounted to the SUTO portable dew point meters through the 1/2“ G-type thread connection Parking and measurement position is selected through the handle at the chamber, which allows quick measurement results A699 3496 Measuring chamber for dryer installation, 2 l/min @ 0.8 MPa, hose fast connector, without filter, max. pressure 1.6 MPa The sample gas/air is connected to the chamber through a 6 mm Teflon® hose The chamber is mounted to stationary S2XX dew point sensors through the 1/2“ G-type thread connection. This chamber can be conveniently mounted to the frame or cabinet of a dryer A699 3590 High pressure chamber up to 35 MPa In applications where the pressure is exceeding 1.5 MPa, this chamber can be used. Through the adjustable valve a small purge is set to ensure a gas flow through the sensor element (response time) A554 0054 Compressed air quick coupling, female side R ½” thread Connect this quick coupling to a 1/2’’ ball valve to set up a quick connector for measurement of dew point, oil and particle Dew point sensor protection caps Protection caps are used to protect the dew point sensor element from mechanical impacts or dust. The proper cap selection depends in application Please contact customer service Ordering Please use the following table to assist in placing your order with our sales staff.
Accessories www.suto-itec.com sales@suto-itec.com International Edition (EN) - 24-4. © 2024 SUTO iTEC GmbH. www.suto-itec.com Ordering Please use the following table to assist in placing your order with our sales staff. Order No. Description Application Picture A554 0002 Test pot 11.3 % rH Is used to check dew point sensors. The pot creates a constant relative humidity of 11.3 %. The resulting dew point is depending on the ambient temperature, at 25 °C it is equal to -6.3 °C D500 0005 S51 panel meter, with 4 ... 20 mA input and 2 alarm outputs, 85 ... 265 VAC supply, 96 x 48 mm panel Installations in dryers or similar equipment as dew point indicator C219 0055 M12 connector with RS-485 termination resistor, 120 Ω Termination resistor for enhancing communication stability of RS-485 network Connect it to the final device of RS-485 network A554 3310 M12 RS-485 (Modbus/RTU) splitter Stationary Modbus/RTU splitter for easier wiring A554 0011 RS-485 Repeater A repeater is used whenever the bus length of RS-485 exceeds 500 m. After every 500 m of cable distance a repeater is recommended A554 0331 RS-485 / USB converter This converter brings RS-485 to the USB port of the PC D554 0031 8-channel current input module, 0 ... 20 mA, Modbus/RTU For connecting up to 8 sensors with 0 ... 20 mA / 4 ... 20 mA signal via RS-485 to S330 / S331 A554 0087 USB OTG memory stick USB memory drive for transferring data between SUTO data loggers (S331 / S551 / S120 with display / S130 with display) and a PC. The USB drive has a USB-A and a Micro-USB connector A699 3302 Wireless DP transmitter adapter for use with S4C-DP application For the wireless connection of SUTO dew point transmitters via the S4C-DP app for smart phones
1/5 Dew Point Transmitters S211 / S215 / S220 S211 -60 … +20 °C Td -20 … +50 °C Td S215 S220 -100 … +20 °C Td Be smart. Measure it. ISO-8573 www.suto-itec.com COMPACT DESIGN Makes it easy to fit into the application SIGNAL OUTPUT 4 ... 20 mA Modbus/RTU PRESSURE SENSOR integrated as option PRECISE MEASUREMENT ± 2 °C Td Accuracy DISPLAY OPTION For on-site values AIR QUALITY Monitors humidity FOR DESICCANT DRYERS FOR REFRIGERATION DRYERS FOR HIGH-TECH APPLICATIONS
2/5 S211/S215/S220 Dew Point Transmitters Benefits Compact size makes them ideal for dryer installations Optional display for on-site values. Display can be rotated by 340 ° to fit your needs User friendly signal outputs to connect to process controls or monitoring systems IP65 casing provides robust protection Low maintenance costs due to stable and reliable measurements which increase calibration intervals Measured values available in several units: °C Td • g/m³ • mg/m³ • ppmv • g/kg (@ reference pressure) • % rH and more The OLED display directly mounted on the device provides on-site real time values. The display can be easily rotated by 340 ° to fit your application. The main body is made from high class aluminum alloy with a soft finish. The process connection is a 1.4301 (SUS 304) stainless steel connection, made to last forever. The top cover and optional display cover are manufactured from durable Polycarbonate and reinforced with ABS to withstand harsh environments. Display Option Robust Materials 3 4 3 5 SUTO can rely on a 20+ years experience in developing dew point sensors used in compressed air systems and pressurized gases. During that period of time, the engineers have continued to develop new measurement methods and even developed own sensor elements for our innovative dew point meters. Reliable Measurement 1 Our QCM sensor is the result of years of high-tech research and development. The sensor was especially designed for low dew point applications where other sensor types fail. The combination of QCM and the well known Polymer sensor makes the S220 the worlds first model to measure accurate over the whole range, from -100 °C Td up to +20 °C Td by switching automatically between the two sensor elements as needed. S220 with unique QCM Sensor 4 2 The Dew Point Meters are perfectly suited to be integrated into process controls or high-level monitoring systems. Various output options are offered for a seamless integration: • 4 ... 20 mA 2-wire + SDI • 4 ... 20 mA 3-wire + SDI • 4 ... 20 mA 3-wire + Modbus/ RTU Various Output Signal 2 5 1
3/5 With display Without display Dimensions With the S220, SUTO is combining three sensors into a single measurement unit, making it unique and the most advanced sensor available on the market, with a full range of -100 ... + 20 °C Td. S220 with unique triple sensor solution The Modbus/RTU bus allows to connect several devices to a single bus line via Daisy-Chain. For example up to 16 devices to a S331. The S331 is a very powerful yet cost effective new data logger and display solution. Modbus Sensor Network with S331 S331 Modbus splitter Modbus splitter Modbus splitter 1 2 16 Modbus/RTU device Modbus/RTU device Modbus/RTU device Pressure Polymer QCM Range of 0 ... 1.6 MPa Best performance -60 ... +20 °C Td Best performance -100 ... -20 °C Td S211/S215/S220 Dew Point Transmitters Model S211 S215 S220 Dew point -60 ... +20 °C Td -20 ... +50 °C Td -100 ... +20 °C Td Temperature -30 ... +70 °C -30 ... +70 °C -30 ... +70 °C Pressure 0 ... 1.6 MPa 0 ... 1.6 MPa 0 ... 1.6 MPa Application In desiccant dryers In fridge dryers In high tech requirements and conditions Measurement Ranges and Applications Exchange Service No Downtime anymore! The exchange calibration service eliminates down time and enables users to have a seamless record of their dew point measurements. The user receives in advance a calibrated instrument with calibration certificate and the same instrument settings. The onsite instrument is then switched against the calibrated one and returned to the supplier. 11mm 132.4mm 136mm 44.5mm 44.5mm 44mm G1/2" SW27 SW27 Ø30mm Ø30mm G1/2"
4/5 Specifications Model S211 S215 S220 Measurement Range Dew point Temperature Pressure -60 ... +20 °C Td -30 ... +70 °C 0 ... 1.6 MPa Dew point Temperature Pressure -20 ... +50 °C Td -30 ... +70 °C 0 ... 1.6 MPa Dew point Temperature Pressure -100 ... +20 °C Td -30 ... +70 °C 0 ... 1.6 MPa Dew point sensor Polymer Polymer Polymer + QCM Operating Pressure -0.1 ... 1.6 MPa -0.1 ... 35.0 MPa optional -0.1 ... 1.6 MPa -0.1 ... 35.0 MPa optional -0.1 ... 1.6 MPa Response time (t90)@4 l/min 0 °C Td ➞ -60 °C Td ≤ 280 sec -60 °C Td ➞ 0 °C Td ≤ 65 sec 0 °C Td ➞ -20 °C Td ≤ 50 sec -20 °C Td ➞ 0 °C Td ≤ 35 sec 0 °C Td ➞ -80 °C Td ≤ 420 sec -80 °C Td ➞ 0 °C Td ≤ 90 sec Accuracy Dew point +/- 1 °C Td (0 ... 20 °C Td) +/- 2 °C Td (-70 ... 0 / +20 ... +50°C Td) +/- 3 °C Td (-100 ... -70 °C Td) Temperature +/- 0.3 °C Pressure 0.5 % FS Process connection G 1/2” (ISO 228/1), stainless steel 1.4301 (SUS 304) Operating conditions Medium Temp.: -30 ... +70 °C / Ambient Temp. : 0 ... +50 °C / Ambient Humidity: 0 ... 100 % rH Materials Casing: Aluminum alloy / Process thread: Stainless steel 1.4301 (SUS 304) / Display cover: PC + ABS Classification / Approval IP65 / CE Sensor protection Sinter filter (stainless steel) Transport & Storage Transport Temperature: -30 ... + 70 °C / Storage Temperature: -20 ... + 50 °C Weight 180 g Measured gases (Medium) Air, Argon, O₂, N₂, CO₂* Output Signal 4 ... 20 mA 2-wire + SDI, 4 ... 20 mA 3-wire + SDI, 4 ... 20 mA 3-wire + Modbus/RTU Sensor types Temperature sensor: Pt100 / Pressure sensor: Piezo resistive type Display option 0.66” OLED display, indicates the measured value and unit Supply Voltage 15 ... 30 VDC S211/S215/S220 Dew Point Transmitters Technical Data Accessories Measuring chamber for easy installation through quick coupling By-pass measuring chamber with 6 mm hose connections as in- and outlet High pressure measuring chamber for applications up to 35.0 MPa M12 Sensor cable with open ends 5 m or 10 m * CO₂ medium: If the S211 is used in CO₂ the range is limited to -40 °C Td The S220 must be set to CO₂ ex works or by using the S4C-DP Service Software + Service Kit (please state at the order if S211 and S220 will be used in CO₂)
S211/S215/S220 Dew Point Transmitters www.suto-itec.com sales@suto-itec.com International Edition (EN) - 24-1. © 2024 SUTO iTEC GmbH. www.suto-itec.com Ordering Please use the following tables to assist in placing your order with our sales staff. Similar to illustration and pictures / MODBUS® word mark and logos Registered trademark of the Modbus Organization, Hopkinton, USA 2-wire Analog & SDI output 3-wire Analog & SDI output 3-wire Analog & Modbus/RTU*3 output 3-wire Analog & Modbus/RTU*3 output With Pressure Sensor Transmitter Model and Range Order No. Order No. Order No. Order No. S215 Dew Point Transmitter -20 ... +50 °C Td S699 1215 S699 2215 S699 3215 S699 4215 S211 Dew Point Transmitter -60 ... +20 °C Td S699 1211 S699 2211 S699 3211 S699 4211 S220 Dew Point Transmitter -100 ... +20 °C Td S699 1220 S699 2220 S699 3220 S699 4220 Options Operating Pressure 0 ... 1.6 MPa A1380 A1380 A1380 A1380 Operating Pressure 0 ... 35.0 MPa A1381*1 A1381*1 A1381*1 N/A*2 Without Display A1389 A1389 A1389 A1389 With OLED Display N/A*2 A1387 A1388 A1388 *¹ A1381: The high pressure option is only available for the models S215 and S211. The S220 can not be used in pressure applications > 1.6 MPa *² N/A: This option is not available for these models *³ Standard Modbus/RTU Settings are Slave Address: last two digits of serial number / Com. Settings: 19200 baud, 8/N/1 Accessories Order No. Description A699 3491 Measuring chamber with quick connector, up to 1.6 MPa, 2 l/min purge @ 0.8 MPa A699 3493 Measuring chamber by-pass, up to 1.6 MPa, 6 mm hose connection as in- and outlet A699 3590 High pressure measuring chamber, up to 35.0 MPa, G 1/4” inner thread process connection A553 0104 Sensor cable, 5 m with M12 connector, open wires, AWG 24 (0.2 mm²) A553 0105 Sensor cable, 10 m with M12 connector, open wires, AWG 24 (0.2 mm²) Output Unit The dew point Transmitter is available with different measurement units for dew point, humidity, temperature and pressure. Standard is: Dew point = °C Td / Temperature = °C / Pressure = bar If you would like to have a different unit as output, please specify it at the order or use the optional Service Kit with the Service Software to change the output unit. For example pressure in PSI or humidity in ppmv. Ordering Example Example: S211 -60...+20 °C Td, 3-wire analog & Modbus/RTU, 0...1.6 Mpa operating pressure, without display Order Code: S699 3211.A1380.A1389
1/3 www.suto-itec.com Portable Compressed Air Purity Analyzer S600 Be smart. Measure it. Leak Management Software LMS Manage your compressed air leaks — Save your time and costs The Leak Management Software (LMS) provides a total solution for leak detection, management and easy report creation. The software comes as a local installation on a PC and works seamlessly with our S531/S532 ultrasonic leak detector. Recording leaks in the field using SUTO S531/S532 leak detector and later importing them to LMS software enables users to gather quantitative leak loss data and easily create powerful reports which provide a full overview of the customers’ leak situation.
2/3 Leak Management Software Convenient User Experience Powerful Analysis Reports FLAT INTERACTION DESIGN Simplify the operation steps LOCAL INSTALLATION Easy to install and save your data locally ONE-CLICK IMPORT AND UPDATE Import and update new leak data just by a simply click EXTENSIVE ANALYSIS REPORT Leak report with all relevant data PERSONALIZED CONFIGURATION Upload your company logo, contact person etc. PRINT CONTENT OPTIONAL Select your desired leaks to be printed Benefits Simple and user-friendly user interface for easy navigation and leak survey handling Reports can be personalized with your own company logo and contact information Save your valuable time in report documentation by having a one-click report Adjust your reports to local specifications by using the integrated unit converter
3/3 Test it for 30 Days! If you want to try LMS we are offering a 30 days trial period with full functionality. When the 30 days are due to expire, in order to continue using the software you need to buy a license. Trial Period Seamless Connection with S531/S532 Leak Management Software (LMS) Order No. Description M599 7045 Leak Management Software (LMS), Local installation, 1 license (bound to local PC)*, one-time payment sales@suto-itec.com * The software license is bound to the local PC, still the same software can be used by multiple users on the same PC. www.suto-itec.com Included in S531/S532 for free When purchasing a S531/S532 ultrasonic leak detector set, one free LMS license is included. Start immediately creating powerful leak reports, without paying extra for additional software licenses. Create a new project on the fly directly via the user interface of S531/S532 . Define project name, cost and unit settings on site via the touch screen user interface. Planing 2 Execution 3 Use the S531/S532 to perform the leakage survey on site, record the found leaks, which saves the flow, costs of leak loses, take photos of the leaks and record voice memos. All to be used later in generating powerful reports. Reporting 5 Generate powerful reports by a simple click of one button. The reports are with your own logo and company info, so you do not have to spend any more time to sort the data and create reports in an external tool, like ord or Excel. After uploading the data to LMS software, users are enabled to easily check the leakage data, add useful information and/or correct date if needed. Preparation 4 Enter your own company information like company name, address and contact person etc. to be later printed automatically on your reports. Initiation 1 Ordering Leak Management Software International Edition (EN) - 24-2. © 2024 SUTO iTEC GmbH. www.suto-itec.com S531 S532
